AI Auto Tracking PTZ Cameras - 翻译中... D7160-4K

Image Sensor

Sony IMX415 1/2.8" CMOS

Effective Pixels

8.29 megapixels, 16:9

Optical Zoom

12× Optical Zoom

Focal Length

f = 4.1–49.2 mm

Aperture

F1.8–F2.68

Horizontal Field of View

70.28° (Wide) – 6.57° (Tele)

Vertical Field of View

42.06° (Wide) – 3.76° (Tele)

Diagonal Field of View

78.36° (Wide) – 7.5° (Tele)

Video Output Format

HDMI (4KP@30/25fps, 1080P@60/59.94/50/30/29.97/25fps, 720P@60/59.94/50/30); USB3.0 (3840*2160P@30fps, 1920*1080P@30fps, 1280*720P@30fps, 640*480P@30fps, 320*240P@30fps; YUY2/NV12/H.264/H.265/MJPG)

Video Compression

H.264, H.265, MJPG, YUY2

Backlight Compensation

Supported

Signal-to-Noise Ratio

≥50dB

Focus

Auto / Manual

Digital Noise Reduction

2D & 3D DNR

Exposure Compensation

Auto / Manual

Input / Output Interfaces

Video Output Interface

HDMI, USB3.0, RJ45, SDI

Video Compression

H.264, H.265, MJPG, YUY2

Ethernet Port

10/100/1000 Mbps adaptive Ethernet port, supports PoE (IEEE 802.3at)

Network Protocols

NDI|HX2, RTSP, RTMP, VISCA over IP, ONVIF, SRT

Control Protocols

VISCA/Pelco-D/Pelco-P; Baud Rate: 2400/4800/9600/38400

Control Interfaces

RS232 (input only), RS485, USB3.0 (UVC1.1), RJ45

PTZ Parameters

Pan Rotation

350° (±175°), speed: 0.1°/s – 100°/s

Tilt Rotation

180° (±90°), speed: 0.1°/s – 80°/s

Presets

Up to 255 presets (10 presets via IR remote control)

General

Operating Systems

Windows 10 / Windows 11 or higher, Android, macOS 10.10 or higher, Linux (UVC supported required)

Power Supply

DC 12V

Current

2.0A (Max.)

Power Consumption

24W (Max.)

Storage Temperature

-20℃~60℃

Storage Humidity

20%~90% RH

Operating Temperature

0℃~40℃

Operating Humidity

20%~80% RH

Product Dimensions (W×H×D)

166 × 165 × 170 mm

Package Dimensions (W×H×D)

285 × 217 × 197 mm

Net Weight

1.6 kg

Gross Weight

2.8 kg
