Model | PM208 | PM212 | PM216 |
Maximum Output Level | 12dB | ||
S/N Ratio | ≥83dB (1MV IN 1V OUT) | ||
THD | ≤0.02% @ 0dB 1KHz | ||
Frequency Response | 20Hz~20KHz±0.5dB | ||
Channel Crosstalk | <-75dB @ 1KHz | ||
MIC IN Impedance | 600Ω | ||
LINE IN Impedance | 10KΩ | ||
Output Impedance | 100Ω | ||
MIC IN | -60dB | ||
LINE IN | -40dB | ||
Stereo IN Impedance | 10KΩ | ||
Channel Gain Control | -30dB | ||
3-Band Equalizer Adjustment Range | ±15dB | ||
HIGH | 12KHz | ||
MID | 4KHz | ||
LOW | 80Hz | ||
Power Supply Output Power | 30W | ||
Power Supply Voltage | 100V-240V/50Hz | ||
Package Dimensions (1 pc) | 424×176×526(mm) | 538×176×526(mm) | 648×176×526(mm) |
Product Dimensions | 370×450×125(mm) | 480×450×125(mm) | 590×450×125(mm) |
Gross Weight (1 pc) | 6.5KG | 7.2KG | 8.5KG |
Net Weight | 4.35KG | 5.6KG | 6.9KG |
